IS 2360–3 ECO 24m white

IS 2360–3 ECO 24m white
EAN: 4007841 057770
E-No: 535954100
The multi-talent for indoors and outdoors. Infrared wall sensor IS 2360-3 ECO, 3 pyro sensors for a 360° angle of coverage, reach can be set up to 12 m, selectable time and twilight threshold, detection zone can be customised with shrouds.
  • UV-resistant plastic
SurfaceMotion detectors
Mains power supply220 – 240 V / 50 – 60 Hz
Settings viaPotentiometers
With remote controlNo
Dimensions (Ø x H)121 x 57 mm
Sensor Technologypassive infrared
InterconnectionYes
Type of interconnectionMaster/master
Interconnection viaCable
Interconnection, numbermax 5 sensors
Application, placeOutdoors Indoors
Application, roomcorridor / aisle changing room function room / ancillary room kitchenette stairwell WC / washroom multi-storey / underground car park outdoors warehouse Indoors
Installation siteceiling
Type of installationSurface wiring
Mounting height2,50 – 6,00 m
Optimum mounting height2,8 m
Mounting height max.6,00 m
Output2000 W
Power consumption0,56 W
With motion detectorYes
Detection angle360 °
Angle of aperture90 °
Sneak-by guardYes
Capability of masking out individual segmentsYes
Electronic scalabilityNo
Mechanical scalabilityNo
Radial reachØ 6 m (28 m²)
Tangential reach radiusØ 24 m (452 m²)
Switching zones972 switching zones
Photo-cell controllerYes
Twilight setting2 – 1000 lx
Twilight setting TEACHNo
Time setting5 s – 15 Min.
Main light adjustableNo
Basic light level functionNo
Output2000 W
Soft light startNo
Continuous lightselectable
Constant-lighting controlNo
Switching output 1, resistive2000 W
Fluorescent lamps, electronic ballast500 W
Fluorescent lamps, uncorrected500 VA
Fluorescent lamps, series-corrected900 VA
Fluorescent lamps, parallel-corrected400 VA
Switching output 1, low-voltage halogen lamps2000 VA
LED lamps < 2 W100 W
LED lamps > 2 W < 8 W300 W
LED lamps > 8 W500 W
Capacitive load in uF176 µF
Switching output 1, number of LEDs / fluorescent lamps8 pcs.
Switching output 1, floatingNo
IP ratingIP54
Protection classII
Ambient temperaturefrom -20 up to 50 °C
MaterialPlastic
Colourwhite
Colour, RAL9010
Manufacturer's Warranty5 years
IDs, certificatesVDE
Includes corner wall mountNo
Cover material deliveryshrouds
